Wednesday, May 22, 2013

Resin Mix Ratio Chart

Here is something that every fabricator will find very handy. A fiberglass mix ratio chart! With this chart you can determine the proper ratio of MEKP to add to your fiberglass resin in order to obtain a desired cure time. I typically aim for around 1% in order to minimize shrinkage within the fiberglass surface. Feel free to print one out for your shop!




Saturday, April 20, 2013

Join the CAF Army!

Whoa, seriously whoa, this whole YouTube thing is just exploding. I wanted to say thank you from the bottom of my heart to all the fans for all your support. The comments on the videos, the likes, the shares, and the favorites from all the fans have really helped my videos gain a ton of exposure, and in doing so have helped bring more people to our team to learn about Car Audio and grow the hobby.

People have often asked how they can help support the channel. I truly enjoy supporting you guys by teaching you what I have learned so it makes me feel so honored that you want to return the favor and do whatever you can to support CAF. Due to this recurring request I decided to create the picture file below. Feel free to download it. What would really help me is if you could put it in your signature on all the different car audio forums that you post on. Help me by being ambassadors for the CAF army! I figure if enough people do this we can continue to grow the family and continue to learn from one another.

I love you all and thank you for the continued support!

~Mark

(Right click >>> Save as )

(If that doesn't work go here and right click then save as)
http://i1342.photobucket.com/albums/o768/caraudiofabrication/ForumSigaARMY_zpsc3ddf518.jpg?t=1366498531

Thursday, April 11, 2013

How to Build a UNIQUE Subwoofer box - Video


Hey guys, in this episode I show you how you can take a seemingly normal box, and make it truly custom and one of a kind, and integrate it into your install, and really give your builds a PROFESSIONAL look.

Here is the video:


The pictures below outline the steps:

1: Laying Out your shapes and ideas:


2: Preparing the shapes for body filler:


3: Applying Body Filler:


4: sanding Bosy Filler:


5: Prepping for Vinyl or Paint:


6: Wrapping the panel and triming:


7: Finished Product:


8: Finished Product:


Got questions? Be sure to comment on the video on youtube or on the CAF facebook page: CAF Facebook If you enjoyed the video check out my others as well on YouTube.

Mark

Tuesday, April 2, 2013

VIDEO - Knukonceptz KNF60 Distribution Block - Car Audio Fabrication First Look


As you guys well know car audio is an ever changing hobby. You may decide to add an amp to your install, or a secondary battery, and there is nothing more frustrating than having to completely re-do your install just to add an additional electrical component. If you take the time to make fiberglass bezels or beauty panels for your wire distribution the thought of making a change to that distribution is terrifying, as you would then have to redo all of your work.

Well now these worries are a thing of the past! Check out my video review of the Knukonceptz KNF60 distribution block.

If you would like an additional product reviewed in the future let me know!

Mark


Thursday, January 31, 2013

Fiberglass Amp Rack 101 – How to Build a Custom Fiberglass Mold to Hide or Support your Amplifier! EVERY STEP!

Learn to make this!

What’s up ladies and gentlemen of the car audio world? Today I bring to you the all inclusive Fiberglass Amp Rack 101 Lesson! Allow me to insert my shameless plug and say that if you enjoy any part of this tutorial, or learned something new, please post a comment, rank this thread, and share with your friends! Also I love when I get new subscribers on my YouTube channel! (www.youtube.com/caraudiofabrication ) Other than that let’s review what you will learn shall we?

Intro:
First off I know I know, this looks like a ton of reading, and a ton of work, but it really is not, it just seems that way because I am outlining every thing I have learned over the years of many car audio installations. When I started learning this I would have done ANYTHING for a write up with the tricks and techniques I am going to show you, but it didn’t exist, so again while it might seem like a lot to read it WILL be WELL worth your time to read through this and watch the videos. Note that some of the videos or somewhat of an “update” to my progress within the step, where as others are much more of an actual step by step instruction. The videos have a run time of a little over an hour, so grab a frosty beverage and some food and sit back! That being said there are a million different ways you could construct an amp rack, this tutorial will cover what I have learned and found to be very effective means of building a professional quality amp rack. Note that for the sake of length some sections of this lesson may refer to previous lesson posts I have made, in these cases I will provide a link for you to visit so that you may learn that technique as well! Also note that the quality of my videos improves throughout the series.

Please watch all the videos to gain the full experience! In order to watch all of the YouTube videos is one go, please view the YouTube playlist here:


Note that each step within this write up also has the video thumbnail, with a link to the video below it.

The Process:
Before we begin allow me to briefly outline the process that will be covered. By understanding each step involved you are well on your way to an amazing fiberglass amp rack!
  1. Designing the Layout
  2. Skeleton – The Foundation of your shape and Making Templates
  3. Prepping Templates and Skeleton for Molding
  4. Applying Fabric – The Skin of your shape
  5. Glassing and Strength
  6. Smoothing and Prep for Finish
  7. Adding Plexi and Inserts
  8. Wrapping the Amp Rack – Vinyl, Suede, and Carpet
  9. Final Thoughts
Let’s begin!

1)     Designing the Layout:

Before you even cut your first piece of wood you are going to want to carefully consider your layout. First off most all amplifier racks should be designed with two pieces in mind. They are 1) The Mounting Structure and 2) the Beauty Panel. The mounting structure is what your amps and equipment will mount too and the beauty panel is the structure that will hide all the wiring and effectively show off your amps. Note that your amp rack could be designed that both these functions are in one piece, but in my case they are separate.

Next you need to layout the equipment. To effectively do this take a picture of the bare trunk and sketch where each piece of equipment will be, and then what you want the finished product to look like. Luckily I have access to modeling software so I perform this step on a computer. The video shows my first step of the design. This is also a great phase to consider the materials you will use to finish the amp rack and their seamless integration into the vehicle. I strongly advise you to consider the “less is more” philosophy in this phase. Often times the best installs are those that are the most simple.



Before continuing to your skeleton here is an excellent list of questions to ask yourself about your design to minimize issues throughout the build.
·         Have I accounted for enough room for all amplifiers, distribution blocks, equalizers/crossovers, and wiring?
·         How will the wiring reach my equipment?
·         Is there enough airspace around my equipment for proper cooling per the manufacturer recommendations?
·         Will my equipment be secure in the way I plan to mount it?
·         Can I easily access all fuses, and adjustments on the equipment?
·         Are all functions of the vehicle still possible? (Moving Seats, Trunk Closing, etc)

If the answers to the above questions are yes, lets continue onto making your wooden skeleton.

2)      Skeleton – The foundation of your shape:


So its time to get to work building your skeleton which will be the foundation for your amp rack. I recommend building your Mounting Structure for your equipment first. This will require basic building techniques so I did not outline much of it within the videos. Some tips are to utilize good mounting techniques for securing the base of the mounting structure. Some of these techniques are to use nutserts (threaded rivets) for mounting to the sheet metal of the vehicle and t nuts for mounting equipment to wood. They are outlined in the following two videos:



Once your mounting structure is complete you will want to start determining what shapes you would like to use for templates that will cover the amplifiers or be around them. I cover how templates are made in a totally separate how to series, as they are pretty involved steps, but once you learn them you are on your way to taking your install to the next level. Check out that how to series here:


When it comes to making the Beauty Panel skeleton you are going to want to utilize techniques like router tricks to make pieces that fit within one another perfectly. You will also want to use techniques that allow you to mesh similar pieces of wood into one another to create separate pieces of the amp rack so that the amp rack is an assembly, rather than one permanently conjoined part. Having an amp rack that is multiple pieces that are joined together by bolts and screws is much more effective than an amp rack that is glued or otherwise permanently joined. You want to have access to the equipment.

The methods and steps to effectively doing this are outlined in the following video:


Once you have all your skeleton pieces built for both supporting the equipment and hiding the equipment you are going to want to prepare the skeleton for fiberglass, the professional way.


3)      Prepping Skeleton and Templates for Molding

Here is where the rabbeting bit and the router come into play. If there was ever one ‘most important step” within the process I would say this is it. This step is often skipped and leads to tons of more effort in the fiberglass stage. Pay close attention to the steps performed here, and follow them!


Following the steps in the video will allow you to cut a perfect step in your skeleton pieces. This step will lead to a flush fiberglass surface that is easier to sand and fill with body filler.


4)      Applying Fabric – The Skin of Your Shape



Here is where your design will really start to become a reality. In this step you are going to stretch material and adhere it to the bounding surfaces of your amp rack. This is where properly preparing your amp rack skeleton will really pay off.

Within the video you will see how I stretch the material properly in a manner that avoids sags and wrinkles, and also how to easily adhere the fabric and trim it perfectly.

Upon completing the stretching of your fabric you are ready to move onto adding some fiberglass strength!


5)      Glassing and Strength:

Now that you have a super clean and functional fabric surface prepared it’s time to add some strength! After all we want our fiberglass amp rack to last for years in the harsh automotive environment, so let’s get to work making it ready for the abuse!

In this step you are going to learn to apply fiberglass resin to the fiberglass, you are also going to learn how to apply fiberglass chop mat. Though there are different techniques that can be used in this stage, this is the method I use and have never had any issues. Note that if you do in fact have access to the “rear” of the panel it is advantageous to apply  the fiberglass mat to the rear. This allows for a smoother surface to sand later on, but in my case I did not have this option.

People who are new to fiberglass are often surprised how simple this step actually is! Watch and enjoy!





6)      Smoothing and Prep for Finish:

So your fabric surface is now nice and strong! So that means it is now time to smooth things out and prepare for the finish that you plan to apply to the fiberglass amp rack. This steps video will teach you how to properly smooth the surface using a high quality body filler. It will also show you techniques that can be used to help decrease the sanding time, a HUGE time saver! Two key points here:

Milkshake:  If you have a relatively horizontal surface you can use what is called a “milk shake” to get things nice and smooth. This is accomplished by mixing body filler and resin with a 3:1 ratio. 3 Parts body filler to 1 part resin. You then add the proper amount of hardener and MEKP that corresponds to the amount of body filler and resin used.  Upon mixing you will note that the body filler will lay down extremely well, and be very level, the downside is that you cannot really do this on vertical surfaces, and the body filler also becomes a little more difficult to sand.

Green Stage Sanding: When sanding body filler you want to be sure you are sanding in the “green stage”. What this means is you want to pay close attention to body filler as it is drying. Every 5-10 minutes take a piece of sand paper and try sanding the body filler. If the body filler still seems like “liquid” then it is NOT ready to be sanded. But if the body filler sands with a “foam-like” consistency, almost as if you are grating cheese, then it is ready to be sanded. You can really sand very effectively in this phase. This is also the key reason to purchase high quality body filler. With Rage Gold you will find the Green stage lasts for 20 mins or more. With Bondo brand… well there doesn’t seem to be a green stage.


Note that in the video I am prepping for a vinyl surface, not paint, so I only sand up to 150 grit. If you were doing paint you would want to sand smoother for the primer application… but that is a different How To.

7)      Adding Plexi and Inserts:


Now that you have smoothed out your main surface it is time for a step that can really make your install look amazing, and help tie everything together. In my design you can see the shape that I utilized over the amplifiers. It is a rounded rectangle of sorts. In order to make the entire amp rack look appealing I want to carry that design to each piece. In order to carry it to my amp rack “trim ring” I want to incorporate the rounded rectangle shape. I do this in the form of an “insert”, and what better to accent the insert than a piece of plexi glass that can be back lit, or have a logo applied.

In this step I show you how through using router skills you can make an exact plexi glass shape and integrate it behind an insert. I also show you how you can use foam tape and body filler to make a perfect gap for the materials you will ultimately finish the amp rack trim piece and insert with. Big tips here are to use a high quality body filler (as you will likely be doing small detail sanding) and to make sure you use foam tape with enough thickness for the materials you use to finish the pieces.




8)      Wrapping the Amp Rack: Vinyl, Suede, and Carpet:

So it’s finally coming all together! You’re ready to finish the amp rack off! In the first video you will learn how I wrap “basic” panels, which basically does not require the use of a heat gun, but requires you to rabbet the edges of the panel for a clean finish on the rear side.  In the second video I will show you how to wrap more complex panels, which requires a more aggressive adhesive as well as the use of a heat gun when using vinyl to properly form the piece and avoid wrinkles.

It is very important that you take your time in this step, do not attempt to secure materials before your adhesive is tacky. If you try adhering the materials to early will pay for it later when the material pulls away from the panel. It is also important when wrapping a complex panel to utilize high quality glue, as I will recommend within the video.



9)      Final Thoughts:

Once all your panels are wrapped you’re obviously ready to piece things back together. It is important to verify things are perfectly secure. The vehicle can be a very dangerous place in the event of an accident, so insure everything is held firmly in place.

If you enjoyed this tutorial please comment below, if you utilize any of the methods in this tutorial please feel free to share pictures within this thread of what you made! I love seeing what my lessons have helped people create! If you have any questions please feel free to post below!

Good luck!

~Mark

Sunday, January 27, 2013

How to Design Your Box in Google Sketchup!


Here you go guys let me know what you think!

What is Google Sketchup?
Sketchup is a free 3d modeling program that is made by Google. It is used around the world for its ease of use and accurate function.

Where do I get it?
Right here:
http://sketchup.google.com/download/ Download the basic version.

What is the advantage?
You can basically "build" your box before you make a single cut! Get an idea what it will look like, even lay out all the boards to make sure you get the most use out of a sheet!

How do I use it?
Watch my video below!


Monday, January 14, 2013

How to keep factory steering wheel controls - Video


Hello all!

In today's day and age many vehicles have controls on the steering wheel for controlling functions and features of your factory sound system. Many are discouraged from moving to an aftermarket head unit for the sole reason that they would then lose these controls.

Well fear no more! This video will show you my experience with the Axxess ASWC - Steering Wheel Control Interface. I found this interface to be extremely easy to use, easy to install, and easy to program. Following the steps outlined within the vehicle will have you well on your way to controlling an aftermarket head unit with your factory steering wheel controls.





I hope you enjoy!
